AEG L7WC8632BI User Manual

The permanent options are
set by holding pressed the
relative button for at least 3
seconds.
1
Programme dial
2
Spin touch button
3
Temp. touch button
4
Display
5
Time Dry touch button
6
Auto Dry touch button
7
Start/Pause touch button
8
Delay Start touch button
9
Mode - Dry touch button and
permanent Anti-crease option
10
Time Save touch button and
permanent Child Lock option
11
Stains touch button and permanent
Soft Plus option
12
Prewash touch button and
permanent Extra Rinse option
13
On/Off push button
14
Mode - Wash touch button
5.2 Display
The Temperature area:
Temperature indicator .
Cold water indicator.
Door locked indicator.
Child safety lock indicator.
The digital indicator can show:
• Programme duration (e. g. , washing and/or drying phase).
• Delay time (e. g. ).
• Cycle end ( ).
• Warning code (e.g. ).
• Error indicator ( ).
ENGLISH 19

AEG L7WC8632BI Specifications

General

Door hinge	Left
Drum volume	52 L
Loading type	Front-load
Product color	White
Built-in display	Yes
Custom panel-ready	-
Appliance placement	Built-in
Annual water consumption washing	11200 L
Annual energy consumption washing	194 kWh
Annual water consumption washing & drying	23000 L
Annual energy consumption washing & drying	1060 kWh
Drying capacity	84 kg
Washing capacity	8 kg
Residual moisture	44 %
Maximum spin speed	1600 RPM
Noise level (spin)	70 dB
Noise level (wash)	46 dB
Noise level (drying)	52 dB
Inlet hose length	1.5 m
Outlet hose length	1.4 m
Connected load	2000 W
AC input voltage	230-240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Energy consumption washing per cycle	0.97 kWh
Water consumption washing & drying per cycle	- L
Energy consumption washing & drying per cycle	5.3 kWh

Weight and Dimensions

Depth	540 mm
Width	596 mm
Height	819 mm
