AEG LA 10 - Charging the Storage Battery; Using the 12 V Vehicle Outlet; Replacing Fuses

▪ Using a pair of flat-nose pliers carefully pull the
flat fuse inside the housing unit for the controls.
▪ Replace the defective fuse with a new 15 A flat
fuse by carefully pushing the new fuse into the
fuse holder with your thumb until it is flush with
the unit housing (see Image 9).
Image 9
Intact flat fuse
15 A (Ampere)
Fuse
▪ Unscrew the retaining screw.
▪ Remove the terminal cap and the 15 A
(Ampere) round fuse.
▪ Assemble all parts with the new 15 A fuse in the
order shown and replace the retaining screw
(see Image 8).
Image 8
12 V vehicle
connector plug
Terminal cap
Round fuse 15 A (Ampere)
Retaining screw
12 V Vehicle plug
4.6 Replacing fuses
▪ The unit's 12 V vehicle jack is now live and the
connected 12 V external device can be oper-
ated (see Image 7).
▪ After using the external device unplug the 12 V
vehicle plug from the 12 V vehicle jack on the
unit.
Image 7
External device
12 V vehicle
plug
▪ Remove the cover from the 12 V vehicle jack.
▪ Connect the 12 V vehicle plug of the external
device to the unit's 12 V vehicle jack.
▪ Set the operating switch to ( I ).
4.5 Using the 12 V vehicle outlet
Note! Do not operate the compressor or
the light whilst charging!
▪ Connect the small round plug on the charging
mains adapter to the receptacle .
▪ Plug the charging mains adapter into a 230 V
power socket.
▪ Set the operating switch to ( I ). The unit will
now switch to charging mode.
▪ The LED display will light up and the blinking
LED will indicate the current storage battery
capacity. The charging time is approx. 10 - 12
hours. The green LED must stay on when the
storage battery is fully charged.
▪ After charging use the operating switch to
power the unit off and disconnect the 230 V
charging mains adapter from the unit and the
230 V outlet.
The storage battery should be fully charged prior
to first use.
Charging by 230 V charging mains adapter
4.4 Charging the storage battery
10
14
13
20
13
24
13
16
