TRIP UNIT
ཌቄڇᇮ
2.5
2.5-05
٪ഗ
55 Reactive PowerPhase TotalHi 16 bits
- Read
56 Power Apparent Ph. L1Lo 16 bits
32 bit Read
57 Power Apparent Ph. L1Hi 16 bits
- Read
58 Power Apparent Ph. L2Lo 16 bits
32 bit Read
59 Power Apparent Ph. L2Hi 16 bits
- Read
60 Power Apparent Ph. L3 - Lo 16 bits
32 bit Read
61 Power Apparent Ph. L3 - Hi 16 bits
- Read
62 Power Apparent Phase Total - Lo 16 bits
32 bit Read
63 Power Apparent Phase Total - Hi 16 bits
- Read
64 Power Demand Total - Hi 16 bits
32 bit Read
65 Power Demand Total - Hi 16 bits
- Read
66 Frequency Measured
16 bit Read
67 Event 1
8 bit Read
68 Year
8 bit Read
69 Month
8 bit Read
70 Date
8 bit Read
71 Hour
8 bit Read
72 Minute
8 bit Read
73 Second
8 bit Read
74 Phase
8 bit Read
75 Event Speci c 1
16 bit Read
76 Event Speci c 2
16 bit Read
77 Event 2
8 bit Read
78 Year
8 bit Read
79 Month
8 bit Read
80 Date
8 bit Read
81 Hour
8 bit Read
82 Minute
8 bit Read
83 Second
8 bit Read
84 Phase
8 bit Read
85 Event Speci
c 1
16 bit Read
86 Event Speci c 2
16 bit Read
87 Event 3
8 bit Read
88 Year
8 bit Read
89 Month
8 bit Read
90 Date
8 bit Read
91 Hour
8 bit Read
92 Minute
8 bit Read
93 Second
8 bit Read
94 Phase
8 bit Read
95 Event Speci c 1
16 bit Read
96 Event Speci
c 2
16 bit Read
97 Event 4
8 bit Read
98 Year
8 bit Read
99 Month
8 bit Read
100 Date
8 bit Read
101 Hour
8 bit Read
102 Minute
8 bit Read
103 Second
8 bit Read
104 Phase
8 bit Read
105 Event Speci c 1
16 bit Read
106
Event Speci c 2
16 bit Read
107 Event 5
8 bit Read
108 Year
8 bit Read
109 Month
8 bit Read
110 Date
8 bit Read
111 Hour
8 bit Read
112 Minute
8 bit Read
113 Second
8 bit Read
114 Phase
8 bit Read
115 Event Speci c 1
16 bit Read
116 Event Speci
c 2
16 bit Read
117 Event 6
8 bit Read
118 Year
8 bit Read
119 Month
8 bit Read
120 Date
8 bit Read
121 Hour
8 bit Read
122 Minute
8 bit Read
123 Second
8 bit Read
124 Phase
8 bit Read
125
Event Speci c 1
16 bit Read
126 Event Speci
c 2
16 bit Read
127 Event 7
8 bit Read
128 Year
8 bit Read
129 Month
8 bit Read
130 Date
8 bit Read
CommunicaƟon register
ENGLISH ENGLISH
131 Hour 8 bit Read
132 Minute 8 bit Read
133 Second
8 bit Read
134 Phase
8 bit Read
135 Event Speci
c 1
16 bit Read
136 Event Speci
c 2
16 bit Read
137 Event 8
8 bit Read
138 Year
8 bit Read
139 Month
8 bit Read
140 Date
8 bit Read
141 Hour
8 bit Read
142 Minute
8 bit Read
143 Second
8 bit Read
144 Phase
8 bit Read
145 Event Speci
c 1
16 bit Read
146 Event Speci
c 2
16 bit Read
147 Event 9
8 bit Read
148 Year
8 bit Read
150 Date
8 bit Read
151 Hour
8 bit Read
152 Minute
8 bit R
ead
153 Second
8 bit Read
154 Phase
8 bit Read
155 Event Speci
c 1
16 bit Read
156 Event Speci
c 2
16 bit Read
157 Event 10
8 bit Read
158 Year
8 bit Read
159 Month
8 bit Read
160 Date
8 bit Read
161 Hour
8 bit Read
162 Minute
8 bit Read
163 Second
8 bit Read
164 Phase
8 bit Read
165 Event Speci
c 1
16 bit Read
166 Event Speci
c 2
16 bit Read
167 Long Time Trip Count
8 bit Read
168 Short Time Trip Count
8 bit Read
169 Instantaneous Trip Count
8 bit Read
170 Ground Fault Sum Trip Count
8 bit Read
179 Shunt 1 Trip Count
8 bit Read
180 Shunt 2 Trip Count
8 bit Read
196 Software Rev
8 bit Read
227 Breaker Position
1-CLOSE, 0-OPEN Read
228 Error Code Log
See Comment
Read
229 Error Code Log
See Comment
Read
230 Error Code Log
See Comment
Read
231 Error Code Log
See Comment
Read
232 Error Code Log
See Comment
Read
233 Error Code Log
See Comment
Read
234 Error Code Log
See Comment
Read
235 Error Code Log
See Comment
Read
236 Error Code Log
See Comment
Read
237 Error Code Log
See Comment
Read
238 Error Counter
1 to 10 Read
239 Long Time pickup State
0-Not in Pickup, 1-Near Pickup, 2-In Pickup Read
Communication Parameters Function 5
Reg. Pa r a m et e r
Values
102 Save Public Default Data
-
103 Save Real Time Clock Registers
-
104 Read Real Time Clock Registers
-
105 Save EPROM Data
-
107 Upload to BIM
-
108 Trip Breaker
0- Reset, 1- Trip
109 Reduced Instantaneous
0- Off, 1- ON
112 Relay 1 State
0- Off, 1- ON
113 Relay 2 State
0- Off, 1- ON
116 Clear All Events
-
117 Clear EPROM
-
118 Clear Energy Total
-
NF1:ဣଚگუഘୟഗ
