43
Connecting the vacuuming hose and vacuuming pipes
0 Insert the hose inserts into the suction hole as in
the picture and turn it to the right until it locks
into place.
To remove the vacuuming hose, twist the hose
inserts to the left and remove. At the other end
of the vacuuming hose, first connect the
vacuuming pipe without hook-in pins and then
the one with pins; do this in such a way that the
hook-in pins are pointed forwards when in the
operating position.
After this the accessory of choice can be attached.
To remove the vacuuming hose, twist the hose inserts to the left and
remove.
Working with the nozzles when wet vacuuming
The nozzles are all attached to the vacuuming pipe by pressing and
twisting and are removed by pulling and twisting.
Spray suction nozzle for carpet
0 When vacuum up liquids from carpets, push the
thin hose located on the nozzle into the
clamping pieces located on both vacuuming
pipes in order to anchor it; it is not used when
wet vacuuming.
Hard flooring adapter (HFA)
0 Attach the hard flooring adapter when
vacuuming smooth floors. Do this by putting the
arrow marked on the HFA and the spray nozzle
for carpet on top of each other (1) and pushing
the HFA in the direction of the second arrow
marked on the HFA (2).
