AEMC 6503 User Manual

8 MegohmmeterModels6501/6503
2.3 Model6501ControlFeatures
kΩ
Ω
M
V
x 10
5
0
1
2
6
7
10
V
FUS
1
2
3
4
5
10
20
10
20
30
0.5
50
(500V)
(1mA)
(5mA)
ΜΩ
2
!
C
42
300
0
100
200
400
500
600
Ω
κΩ
4
3
8
9
40
0
Ω
MEGOHMMETER
Model 6501
INSTRUMENTS
®
600V CAT II / 1000V CAT I
!
1
2
3
4
5
6
7
8
9
Figure 2-1
1. Line(-)terminalBlack
2. Fuse0.2A
3. Earth(+)terminalRed
4. AmberLEDilluminateswhenpropercrankspeedisattained,
indicatingpresenceofselectedoutput
5. Foldawayhandle
6. Mechanicalzeroadjustmentscrew
7. Rangeswitch-safetytestrstonMΩ/Vrangeto600V
AC
8. Autoranging:RedLEDilluminateswhenreadingneedstobe
multipliedx10toobtainthetruevalue(MΩ,kΩ,Ωranges)
9. Securityngerrestisolatesusershandfromterminalswhile
givingarmgripduringanoperation
