AEMC 6503 User Manual

10 MegohmmeterModels6501/6503
CHAPTER 3
SPECIFICATIONS
MODELS 6501 6503
ELECTRICAL
Insulation Tests
Test Voltage 250V
500V
1000V
−
0.5 to 5.5M
Ω; 5.5 to 200MΩ
−
1 to 11M
Ω; 11 to 500MΩ
1 to 11MΩ; 11 to 500MΩ
10 to 110MΩ; 110 to
5000M
Ω
Short Circuit
Current
5mA (max)
Accuracy 2.5% of Scale Length
Resistance Tests
Measurement
Range
(Auto-Ranging)
0 to 45k
Ω; 45 to 500kΩ
−
DC Test Current 1mA constant, 500V max −
Accuracy 2.5% of Scale Length −
Automatic
Discharge
5s/µF 8s/µF
Continuity Tests
Test Voltage
5mA constant, 10V max −
Measurement
Range
(Auto-Ranging)
0 to 9Ω; 10 to 100Ω
−
Accuracy 2.5% of Scale Length −
Fuse Protection 0.2A, 600V HPC 6x32mm −
Voltage Tests/Safety Check
Voltage Range 0 to 600VAC
Frequency 45 to 450Hz
Accuracy 3% of Scale
Input Impedance
100kΩ (approx)
