MegohmmeterModels6501/6503 17
4.6 InsulationMeasurement-Connections
Figures 4-4 shows the connections to measure the insulation of
one conductor to the other conductors. The cable should be dis-
connectedatbothendstoavoidleakagethroughswitchboardsand
panels.FortheModel6503,theconnectiontotheguardterminal
isusedtoeliminatetheeffectsofsurfaceleakageacrossexposed
insulationatoneendofthecable.RefertothesectiononUtilization
oftheGuardTerminal(§4.5).
G
Cable Insulation
Conductor Under Test
Cable Insulation
6501
6503
Conductor Under Test
Fus
Figure 4-4
