Aeotec Recessed Door Sensor 7 User Manual

AEOTEC Engineering Specification
Page 2
2 FEATURES & SPECIFICATIONS
2.1 Structural Characteristics
Parameter
Value
Product Identifier
ZW187
Dimensions
Main Sensor: Φ19.2×64mm Magnet Sensor: Φ22×13mm
Weight
30g
Color
White
Shell Material
ABS
Shell Fire-proof Level
UL94 V-0
Waterproof and Dustproof
Rated IP20 under IEC 60529
Usage
For indoor use. Can be embedded inside the wooden door or window.
Operating Temperature
32~104°F (0~40°C)
Relative Humidity
8%~80%
2.2 Hardware Characteristics
Parameter
Value
Z-Wave Module
ZGM130S1852B014A7
Z-Wave TX Power
Max: 13dBm
Z-Wave Antenna Distance
40m (Indoor) /150m (Outdoor)
Indicator Light Color
Red
Buttons and Connectors
Action Button (x1), Magnet(x1)
Input Voltage
3.0V Lithium battery
Battery Included
Yes. 1pcs battery included.
Battery Required
Yes. 1pcs battery required.
Battery Info
Model: CR2
Capacity: 800mAh
Detachable: Yes
Chargeable: No
Endurance: 2 years
Working Current
30mA
Standby Current
10uA (Inside the Z-Wave network) / 50uA(Outside the Z-wave network)
Maximum Standby
Power Consumption
0.03mW
Built-in Sensors
Reed switch
Safety Certifications
US: FCC/ETL
EU: CE
AU: RCM
2.3 Software Characteristics
Parameter
Value
Wireless Technology
Z-Wave
Certification Type
Z-Wave Plus v2 Certification
Z-Wave SDK Version
7.11.0.GA (7.11)
Z-Wave Library Type
Enhanced 232 Slave
Z-Wave Role Type
ZWAVEPLUS_INFO_REPORT_ROLE_TYPE_SLAVE_SLEEPING_REPORTING (0x06)
Generic Device Type
GENERIC_TYPE_SENSOR_NOTIFICATION (0x07)
Specific Device Type
SPECIFIC_TYPE_NOTIFICATION_SENSOR (0x01)
