6. Technical specications
Eects
Internal eect Digital eect processor
1 Reverb with short predelay
2 Reverb with long predelay
3 Delay (320ms, repetitive)
4 Chorus
Parallel eect loop, see send and return
efx pan Blends both internal and external eects
between channels 1 and 2, with reverse
direction of rotation for the external eects
Power amp
Construction Monolithic IC with DMOS output
Output power 60 W / 4 ohms (THD = 1%)
Continuous output power is determined
by limiter, see limiter threshold.
General
Distortion THD + N < 0.1% (6 W / 4 ohms),
measured at loudspeaker terminals
Noise Residual noise (A-weighted SPL):
approx. 17 dB (A) / 1 m
See also inputs and outputs for noise data.
Analog signal
processing Subsonic lter, adaptive peak limiter
Limiter
threshold 50 W / 4 ohms
Speaker system 8” (200 mm) dual cone full-range
speaker, bass reex enclosure
Mains power Mains voltage (depending on model):
100, 120, 220, 230, or 240 V~, 50–60 Hz
Power consumption: max. 120 W
Mains fuse Size: 5 x 20 mm
For 220, 230, 240 V models: T 1A L 250V
For 100, 120 V models: T 2A L 250V
Operating 0…35 °C
temperature range
Cabinet 12 mm (0.47”) birch plywood
Finish Waterbased acrylic, black spatter nish
Dimensions and weight
Dimensions 260 mm (10.2“) high
205 mm (12.8“) wide
235 mm (9.25“) deep
Weight 6.5 kg (14.3 lbs)
Notes
Options congurable by internal jumpers (refer
modication to qualied personnel):
· 9 V phantom power for channel 1.
Caution: Phantom power may damage external
equipment. Read the notes in the operating
instructions.
· Low-gain option (more headroom) for mic input
· Deactivation of 48 V phantom power for mic input
DEFINITIONS
Rated conditions
· Nominal input voltage at input under test
· master fully clockwise
· high / low and colour o
· bass / middle / treble / pan centered
· gain of unused inputs and efx level fully anticlockwise
· gain of input under test adjusted to nominal output
voltage at line out. (This condition corresponds by design
to the rated output power.)
Nominal input voltage: Standard condition for specications,
if not stated otherwise.
Minimum input voltage: Input voltage required for nominal
output with maximum gain and volume settings.
Maximum input voltage: Input voltage that does not cause
distortion more than rated THD+N, suitable control settings
provided.
Nominal output voltage or power refers to rated conditions.
THD + N: Total harmonic distortion + noise, input
voltage reduced by 10 dB after setting up rated
conditions.
Signal / noise ratio: Ratio of output voltage at rated
conditions to output noise voltage with input shorted.
Equivalent input noise voltage: Noise voltage at loudspeaker
terminals divided by gain of amplier. Input shorted after
setting up rated conditions.
Residual noise: Output noise with minimal gain and volume
settings.
Adaptive limiter: Adaptive with respect to power supply.
Maintains constant headroom regardless of power supply
uctuations.
General: Signal voltages are RMS values. Test signal sine 1 kHz
sine unless stated otherwise. Noise measured from 20 Hz to
20 kHz. Noise stated for a specic input implies that all other
inputs are not used. Sound pressure level (SPL) based on louds-
peaker specication by manufacturer.
Specications and appearance subject to change without
notice.
TD20160511 (Compact 60/3)
