6. Donnée techniques
Traitement de signaux analogique
Filtre anti-résonnance, limiteur de pointe
adaptatif
Limiter threshold50 W / 4 ohms
Système d’enceinte Enceinte complète double cône
8“ (200 mm), , caisson reex de graves
bass reex enclosure
Alimentation électrique
Tension secteur (selon le modèle): 100, 120,
230, ou 240 V, 50-60 Hz Puissance absorbée :
max. 100 W
Mains fuse Size: 5 x 20 mm
For 230 and 240 V models: T 1A L 250V
For 100 and 120 V models: T 2A L 250V
Plage de température de fonctionnement
0…35 °C
Coret électrique
12 mm (0.47”) birch plywood
Peinture Acrylique à l’eau, nition noire type
éclaboussures rbased acrylic, black spatter
nish
Dimensions and weight
Dimensions 260 mm (10.2“) de haut
205 mm (12.8“) de large
235 mm (9.25“) de profondeur
Poids 6.1 kg (13.5 lbs)
Notes
Options congurable by internal jumpers (refer
modication to qualied personnel):
· 9 V phantom power for channel 1.
Caution: Phantom power may damage external
equipment. Read the notes in the operating
instructions.
· Low-gain option (more headroom) for mic input
· Deactivation of 48V phantom power for mic input
DEFINITIONS
Rated conditions
· Nominal input voltage at input under test
· master fully clockwise
· high / low and colour o
· bass / middle / treble / pan centered
· gain of unused inputs and efx level fully anticlockwise
· gain of input under test adjusted to nominal output
voltage at line out. (This condition corresponds by design
to the rated output power.)
Nominal input voltage: Standard condition for specications,
if not stated otherwise.
Minimum input voltage: Input voltage required for nominal
output with maximum gain and volume settings.
Maximum input voltage: Input voltage that does not cause
distortion more than rated THD+N, suitable control settings
provided.
Nominal output voltage or power refers to rated conditions.
THD + N: Total harmonic distortion + noise, input
voltage reduced by 10 dB after setting up rated
conditions.
Signal / noise ratio: Ratio of output voltage at rated
conditions to output noise voltage with input shorted.
Equivalent input noise voltage: Noise voltage at loudspeaker
terminals divided by gain of amplier. Input shorted after
setting up rated conditions.
Residual noise: Output noise with minimal gain and volume
settings.
Adaptive limiter: Adaptive with respect to power supply.
Maintains constant headroom regardless of power supply
uctuations.
General: Signal voltages are RMS values. Test signal sine 1 kHz
sine unless stated otherwise. Noise measured from 20 Hz to
20 kHz. Noise stated for a specic input implies that all other
inputs are not used. Sound pressure level (SPL) based on louds-
peaker specication by manufacturer.
Specications and appearance subject to change without
notice.
