Aerco AM Series Application Guide

Page 17 of 30 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 PR1 04/08/2014
GF-146-P
TAG-0074 0B
AM Series Piping
Application Guide
Figure 6b: AM 750/1000 Rear Panel Connections
AUTOMATIC AIR
VENTS
HEADER
TEMPERATURE
SENSOR
SAFETY RELIEF VALVE
WATER SUPPLY
(OUTLET) CONNECTION
WATER RETURN
(INLET) CONNECTION
DRAINING VALVES
PRESSURE AND
TEMPERATURE GAUGE
HEADERS
