AERMEC ANL 021 - ANL 021-041 Dimensions (Version C); Hydraulic Connection Points and Pipe Sizes

16
354
310
Ø 12.70 L
Ø 15.88 G
194.5
70
130
1000
900
650
330
Ø 9
895
122,50 122,50
Gx
Gy
Power cable entry points
A
D
CB
AC
B
D
ANL 021 ÷ 041 VERSION C
WARNING
For the weight distribution refer to
versions °
Mod. A B C D
VT9 40 30 23 M8
ANL GAS LIQUID
021-026 15,88 ø 9,52 ø
031-041 15,88 ø 12,70 ø
ø GAS
ø LIQUID
