22
HEATING CAPACITY OUTPUT 4-PIPE SYSTEM CONFIGURATION 20°C d.b.; Water (in/out) 65°C/55°C; (EUROVENT)
FCLI34
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
W W W W W
70
5
2915 2789 2665 2542 2422
10
2849 3301 2600 2478 2355
15
2771 2645 2520 2396 2275
65
5
2639 2515 2392 2270 2151
10
2568 2446 2323 2201 2080
15
2485 2361 2236 2114 1993
60
5
2448 2323 2197 2075 1952
10
2288 2166 2045 1924 1806
15
2197 2075 1952 1830 1709
50
5
1808 1687 1568 1451 1336
10
1724 1603 1483 1364 1245
15
1615 1490 1366 1242 1117
45
5
1529 1410 1294 1177 1062
10
1436 1318 1197 1078 958
15
1312 1186 1058 926 792
40
5
1249 1132 1017 900 787
10
1147 1024 904 781 655
15
995 859 696 453 260
FCLI44
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
W W W W W
70
5
3443 3294 3147 3002 2860
10
3364 3898 3070 2925 2781
15
3272 3123 2976 2829 2687
65
5
3116 2969 2825 2680 2540
10
3033 2888 2743 2599 2456
15
2934 2787 2641 2496 2353
60
5
2890 2743 2594 2450 2305
10
2702 2557 2415 2272 2132
15
2594 2450 2305 2161 2018
50
5
2134 1992 1852 1714 1578
10
2036 1893 1751 1611 1470
15
1906 1760 1613 1466 1319
45
5
1806 1665 1527 1389 1253
10
1696 1556 1413 1273 1131
15
1549 1400 1249 1093 936
40
5
1475 1337 1201 1063 929
10
1354 1210 1067 923 774
15
1175 1015 822 535 307
FCLI64
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
W W W W W
70
5
4003 3830 3659 3491 3325
10
3911 4533 3570 3402 3234
15
3804 3631 3460 3290 3124
65
5
3624 3453 3285 3116 2953
10
3527 3359 3190 3022 2857
15
3412 3241 3071 2902 2737
60
5
3361 3190 3017 2849 2681
10
3142 2974 2808 2642 2479
15
3017 2849 2681 2513 2347
50
5
2482 2316 2153 1993 1835
10
2367 2202 2036 1873 1710
15
2217 2046 1875 1705 1534
45
5
2100 1937 1776 1616 1458
10
1972 1809 1644 1480 1315
15
1802 1628 1452 1272 1088
40
5
1715 1554 1396 1236 1080
10
1575 1407 1241 1073 900
15
1366 1180 956 622 357
FCLI124
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
W W W W W
70
5
14017 13410 12812 12223 11643
10
13696 15873 12500 11911 11322
15
13321 12714 12116 11519 10939
65
5
12687 12090 11501 10912 10341
10
12348 11759 11171 10582 10002
15
11947 11349 10751 10162 9582
60
5
11768 11171 10564 9975 9386
10
11001 10412 9832 9252 8681
15
10564 9975 9386 8797 8217
50
5
8690 8110 7539 6977 6424
10
8289 7709 7129 6558 5987
15
7762 7165 6567 5969 5371
45
5
7352 6781 6219 5657 5103
10
6906 6335 5755 5184 4604
15
6308 5701 5086 4452 3810
40
5
6005 5443 4889 4327 3783
10
5514 4925 4345 3756 3150
15
4782 4131 3346 2177 1249
HEATING CAPACITY CORRECTION FACTORS
The heating capacity refers to the maximum speed. For the others the speeds, the values must be multiplied by the following fac-
tors:
FCLI 32 34 42 44 62 64 82 124 122
speed 3 1 1 1 1 1 1 1 1 1
speed 2 0.30 0.20 0.45 0.20 0.64 0.25 0.81 1.47 0.83
Speed 1 (minimum) 0.22 0.17 0.33 0.18 0.52 0.22 0.59 1.05 0.63
