AERMEC FCLI 64 - PRESSURE DROPS (COOLING); Standard Coil Cooling Pressure Drop; PRESSURE DROPS (HEATING); Secondary Coil Heating Pressure Drop

23
PRESSURE DROPS WITH STANDARD COIL IN COOLING
PRESSURE DROPS WITH SECONDARY COIL IN HEATING
0
20
40
60
80
100
120
140
160
180
0 500 1000 1500 2000 2500 3000 3500
FCLI 32
FCLI 34
FCLI 42
FCLI 44
FCLI 62
FCLI 64
FCLI 82
FCLI 122
FCLI 124
CALDO
Coil pressure drops [kPa]
Water flow rate [l/h]
Water flow rate [l/h]
Coil pressure drops [kPa]
0
20
40
60
80
100
120
140
160
180
0 500 1000 1500 2000 2500 3000 3500
FCLI 32
FCLI 34
FCLI 42
FCLI 44
FCLI 62
FCLI 64
FCLI 82
FCLI 122
FCLI 124
CALDO
