Qwc = [(Pf + Pa) x 860] / ∆t = [(82,95 + 18,41) x 860] / 5 =
17.387 l/h
Volendo ridurre la portata d’acqua da inviare al conden-
satore si potrebbe lavorare con un ∆t = 10 °C, pertanto,
la temperatura in uscita al condensatore Twc è facilmente
determinabile:
Twc = Tw + ∆tc = 25 + 10 = 35 °C
Utilizzando le curve di tavola 1, in corrispondenza di una
temperatura dell’acqua prodotta all’evaporatore di 7°C e
con una temperatura acqua in uscita dal condensatore di
35°C ottengo:
per l’evaporatore
F.c.Cf = 1
F.c.Ca = 1
mentre per il condensatore che ha un ∆tc diverso da quello
nominale
F.c.Cf = 1,01
F.c.Ca = 0,99
Si ottiene quindi:
Pf = Pf
(nominale)
x 1 x 1,01 = 82,95 x 1 x 1,01 = 86,80
Pa = Pa
(nominale)
x 1 x 0,99 = 18,41 x 1 x 0,99 = 18,23
In tal caso la portata d’acqua all’evaporatore diviene:
Qwe = (Pf x 860) / ∆t = (86,80 x 860) / 5 = 14.929 l/h
Quella al condensatore diviene:
Qwc = [(Pf + Pa) x 860] / ∆t = [(86,80 + 18,23) x 860] / 10
= 18.065 l/h
Dalle tavole 6 e 7 si possono determinare, in funzione delle
portate, le perdite di carico degli scambiatori riferite ad un
temperatura media dell’acqua di 10 °C, che devono essere
corrette con i coefficienti moltiplicativi riportati in calce alla
tavola 8 per temperatura medie diverse. Nel caso in esame:
Tme = temperatura media acqua all’evaporatore
= (Twe + (Twe + ∆te))/2 = (7+(7 + 5))/2 ≈ 10 °C
pertanto il fattore di correzione in tal caso è pari all’unità,
Tmc = temperatura media acqua al condensatore
= (Tw + Twc)/2 = (25 + 35)/2 = 30 °C
pertanto il fattore di correzione in tal caso è pari a 0,95.
Dpe = perdite di carico all’evaporatore
= Valore tavola 4 x coefficiente correttivo = 58 kPa
= 58 kPa x 1 = 58 kPa
Dpc = perdite di carico al condensatore
= Valore tavola 5 x coefficiente correttivo = 87 kPa
= 87 kPa x 0,95 = 82,65 kPa
Alle perdite di carico all’evaporatore devono essere aggiun-
te le perdite di carico del filtro ricavabili dalla tavola 9.
Note: Per il funzionamento in pompa di calore la tavola 2
fornisce le potenze termiche e le potenze assorbite in fun-
zione di Twe e Twc, per le portate da inviare agli scambiato-
ri usare le relazioni seguenti:
Qwc (l/h) = [(Pt x 860) / ∆tc]
Qwe (l/h) = {[(Pt - Pa) x 860] / ∆te}
LEGENDA
Tw = Acqua ingresso al condensatore
Twe = Acqua in uscita all’evaporatore
Twc = Acqua in uscita al condensatore
Qwe = Portata acqua all’evaporatore
Qwc = Portata acqua al condensatore
Dpe = Perdita di carico all’evaporatore
Dpc = Perdita di carico al condensatore
Qwc = [(Pf + Pa) x 860] / ∆t = [(82,95 + 18,4) x 860] / 5 =
17,387 l/h
To reduce water flow to the condenser, an ∆t = 10 °C could
be used, thus, the water temperautre at the condenser outlet
Twc can be obtained as follows:
Twc = Tw + ∆tc = 25 + 10 = 35 °C
On the basis of the curves in Tav. 1, at a water temperautre
produced by the evaporator of 7 °C and a water temperatu-
re produced by the condenser of 35 °C:
for the evaporator
F.c.Cf = 1
F.c.Ca = 1
but for the condenser with a Dtc which is different from the
nominal one
F.c.Cf = 1,01
F.c.Ca = 0,99
Therefore you will get:
Pf = Pf
(nominal)
x 1 x 1,01 = 53,5 x 1 x 1,01 = 86,80
Pa = Pa
(nominal)
x 1 x 0,99 = 15,9 x 1 x 0,99 = 18,23
In this case the evaporator water flow will be:
Qwe = (Pf x 860) / ∆t = (86,80 x 860) / 5 = 14.929 l/h
The condenser water flow will be:
Qwc = [(Pf + Pa) x 860] / ∆t = [(86,80 + 18,23) x 860] / 10
= 18.065 l/h
According to the flow, tables 6 and 7 can determine the
pressure drop values of the exchangers with reference to
an average water temperature of 10 °C; the values are cor-
rected by the multiplication coefficients at the bottom of
table 8 for different average temperatures. In this case:
Tme = average temperature of evaporator water
= (Twe + (Twe + ∆te))/2 = (7+(7 + 5))/2 ≈ 10 °C
therefore the correction factor is equal to the unit,
Tmc = average temperature of condenser water
= (Tw + Twc)/2 = (25 + 35)/2 = 30 °C
therefore the correction factor is equal to 0,95.
Dpe = evaporator pressure drop
= Value given by table 1 x correction coefficient
= 58 kPa x 1 = 58 kPa
Dpc = condenser pressure drop
= Value given by table 2 x correction coefficient
= 87 kPa x 0,95 = 82,65 kPa
The pressure drop by the filter (table 9) are added to the
evaporator pressure drop.
Note: In the case of heat pump operation, table 2 indicates
the heating capacity and the absorbed power values accor-
ding to Twe and Twc; for flow to the exchangers, use the
following formulas:
Qwc (l/h) = [(Pt x 860) / ∆tc]
Qwe (l/h) = {[(Pt - Pa) x 860] / ∆te}
KEY
Tw = Inlet water temperature to condenser
Twe = Evaporator outlet water temperature
Twc = Water temperature at the condenser outlet
Qwe = Evaporator water flow
Qwc = Condenser water flow
Dpe = Evaporator pressure drop
Dpc = Condenser pressure drop
