AERMEC RPLI User Manual

24
WIRING DIAGRAM LABEL - RPLI 030P - 050P - 070P - 100P - 140P - 200P
cod. schema 072E001
cod. 0660034 R3G280RP54B1
cod. 0660033 R3G250RO40A1
cod. 0660035 R3G225RE0703
GNYE - PE GN(GY) - Signal 10V BU - N BN - +10Vdc WH(BK) - GND Signal
SUPPLY FAN
BN - 230Vac
EXHAUST FAN
ZULUFT VENTILATOR ABLUFT VENTILATOR
VENTILATORE RIPRESAVENTILATORE MANDATA
VENTILATEUR REPRISEVENTILATEUR SOUFFLAGE
GNYE - PE GN(GY) - Signal 10V BU - N BN - +10Vdc WH(BK) -GND Signal BN - 230Vac
rev.01
ET00055
WIRING DIAGRAM LABEL - RPLI 300P
cod. 0660036 R3G355RG5601
10V - Signal
400Vac 50/60Hz 400Vac 50/60Hz
400Vac 50/60Hz
GY BN WH BN GN YE GY PK
SUPPLY FAN
VENTILATORE RIPRESA
VENTILATORE MANDATA
VENTILATEUR REPRISE
EXHAUST FAN
VENTILATEUR SOUFFLAGE
ABLUFT VENTILATOR
ZULUFT VENTILATOR
GNYE BK PK GY YE GY BN WH BN GN
GND - Signal NC - Alarm exhaust 1 COM - Alarm exhaust 1
GNYE BK
400Vac 50/60Hz 400Vac 50/60Hz +10Vdc - Voltage output
400Vac 50/60Hz
NO - Alarm exhaust 1 +10Vdc - Voltage output 10V - Signal GND - Signal NC - Alarm supply 1 COM - Alarm supply 1 NO - Alarm supply 1
rev.02
ET00051
