ACCESSORIES
Ø 20
A
120
B
A
Ø 20
83

BC4
BC6

Made with thermoplastic material, it collects and conveys condensate that forms close to non-insulated hydraulic connections during
summer operation outwards.
• The BC4 tray must be used for all sizes with
vertical device installation.
• Tray BC6 must be installed on units with
horizontal installation.
• Tray  must be installed on units with
horizontal installation.
Attention

with:
- VCF
- VCFD
- VCF_X4
AUXILIARY CONDENSATE DRIP TRAY




It allows you to drain condensate by means of a pump when it is necessary to exceed level differences. It is mounted outside the device.






- VCF 

DSC4 
