KEY
1
Filter
2 3 bar safety valve
3 Draining tap
4 Circuator
5 Flow meter
6 NTC 10K water probe L=1.5 M
7 Condenser
8 Evaporator
9 Storage
10 Relief valve
11 Condenser side flow meter
12 Condenser side filter
TAB. 02 HEAT PUMP VERSIONS
