EDACS REPEATERS
1-6
Automatic test parameters (continued)
Tx S/N TEST TXSN
Status OFF STATUS {ON/OFF}
Averages 5 AVERAGES <expr>
Modulation level 1.5 kHz MODLEVEL <expr> [<units>]
Tx filter 0.3-3.4 kHz BP TXFILTER {NONE/LP15KHZ/LP300HZ/
STDBP/CCITT/CMESS}
Lower limit 30 dB LOWER <expr> [<units>]
Tx noise TEST TXNOISE
Status ON STATUS {ON/OFF}
Averages 5 AVERAGES <expr>
Tx Filter 300 Hz LP TXFILTER {NONE/LP15KHZ/LP300HZ/
STDBP/CCITT/CMESS}
Upper limit 300 Hz UPPER <expr> [<units>]
Tx limiting TEST TXLIMIT
Status ON STATUS {ON/OFF}
Averages 5 AVERAGES <expr>
Modulation level 1.5 kHz MODLEVEL <expr> [<units>]
Tx filter 15 kHz LP TXFILTER {NONE/LP15KHZ/LP300HZ/
STDBP/CCITT/CMESS}
Overload factor 20 dB OVERLOAD <expr> [<units>]
Upper limit 2.5 kHz UPPER <expr> [<units>]
Tx compression TEST TXCOMPRESS
(not normally used in EDACS)
Status OFF STATUS {ON/OFF}
Averages 5 AVERAGES <expr>
Modulation level 1.5 kHz MODLEVEL <expr> [<units>]
Tx filter 0.3-3.4 kHz BP TXFILTER {NONE/LP15KHZ/LP300HZ/
STDBP/CCITT/CMESS}
Reference 2 REF <expr>
Error tolerance 10% ERROR <expr> [<units>]
Rx SINAD TEST RXSINAD
Status OFF STATUS {ON/OFF}
Averages 5 AVERAGES <expr>
RF level -80 dBm RFGENLEVEL <expr> [<units>]
Modulation level 1.5 kHz MODLEVEL <expr> [<units>]
Rx filter 0.3-3.4 kHz BP RXFILTER {NONE/LP15KHZ/LP300HZ/
STDBP/CCITT/CMESS}
Lower limit 20 dB LOWER <expr> [<units>]
Rx distortion TEST RXDISTN
Status ON STATUS {ON/OFF}
Averages 5 AVERAGES <expr>
RF level -80 dBm RFGENLEVEL <expr> [<units>]
Modulation level 1.5 kHz MODLEVEL <expr> [<units>]
Rx filter 0.3-3.4 kHz
BP
RXFILTER {NONE/LP15KHZ/LP300HZ/
STDBP/CCITT/CMESS}
Upper limit 10% UPPER <expr> [<units>]
