EDACS REPEATERS
2-8
POLARITY
The transmitted FSK modulation has the property of polarity, which you can select to be
NORMAL or INVERTED
Radio parameters
The RADIO PARAMETERS menu, shown in Fig. 2-7, enables you to change the numbers within the
Service Monitor for
TESTSET LOGICAL IDENTITY, RADIO LOGICAL IDENTITY and GROUP
IDENTITY.
Fig. 2-7 Radio parameters menu
TESTSET LOGICAL IDENTITY
Th
e Testset logical identity number is a unique number used by the Service Monitor. It is
transmitted from the Service Monitor during signaling procedures. The Testset logical identity
parameter allows you to change the number.
The logical identity consists of a decimal number between 0 and 16383.
RADIO LOGICAL IDENTITY
Th
e radio logical identity number is the logical identity of a radio to be used in conjunction with
the Service Monitor. It is transmitted from the Service Monitor during signaling procedures. The
radio logical identity parameter allows you to change the number. Note that if the Service Monitor
‘sees’ a radio make a call to the group identity specified in the
GROUP IDENTITY field, the radio’s
logical identity is set into this parameter.
The logical identity consists of a decimal number between 0 and 16383.
GROUP IDENTITY
The group identity num
ber is a number allocated to a group of radios. The group number is used
in a similar manner to the radio identity. It is used to call all the radios having the same number.
The Service Monitor responds to calls made to this group and places calls to this group.
The group identity consists of a decimal number between 0 and 2047.
Autorun control
The AUTORUN CONTROL menu, shown in Fig. 2-8 on page 2-9, allows you to select how the
Autorun program responds to the results of tests. The soft keys on the right each give access to a
further level of soft keys. This allows you to select options as to the running and results
presentation of the autorun test programs.
