WT-9 Dynamic Club S FLIGHT MANUAL Section 2 Page 2-
4
Powerplant instrument markings and their colour code significance are shown below:
Instrument Unit
Red Line
Minimum
Limit
Green Arc
Normal
Operating
Yellow
Arc
Caution
Range
Red Line
Maximum
Limit
Tachometer rpm 1 400 1 800 – 5 500 5500–5800 5 800
Oil temperature
indicator
o
C 50 90 – 110
50 – 90
110 – 130
130
Cylinder-head
coolant
temperature
o
C
90 – 110
50 – 90
110 – 120
120
Cylinder-head
temperature
indicator
o
C 90 – 110 110 – 135 135
Fuel-pressure
indicator
bar 0,15 0,4
Oil-pressure
indicator
bar 0,8 0,8 – 5 5 – 7 7
Fuel indicator
l
2.6 Miscellaneous instrument markings
According to option of the customer miscellaneous instrument can be mounted. The
following miscellaneous instrument markings and their colour code significance are
shown below:
Instrument Unit
Red Line
Minimum
Limit
Green Arc
Normal
Operating
Yellow
Arc
Caution
Range
Red Line
Maximum
Limit
Boost-pressure
gauge
in Hg
11,8
11,8-28 28-29,5 29,5
Fuel reserve
indicator
Red light annunciator will be illuminated with the
remaining fuel of 7 litre in each fuel tank.
Date: 1.12.2001 „Appr“
