Aerospool WT-9 Dynamic - Instrument Panel

WT-9 Dynamic Club S FLIGHT MANUAL Section 7 Page 7-
3
7.4 Instrument panel
The standard instrument panel arrangement is shown in the following figure ( fig.9 ).
A different instrument panel arrangement may be used, if optional flight and
navigation instruments are mounted in the airplane.
Photo of instrument panel
Fig. 9. Instrument panel
1. Annunciator lights: Smoke, Fuel
pump, Over speed,
Charge, NET, Reserve
Left – Right
2. Airbox temperature
3. Airspeed indicator
4. FlyDEK D-180
5. 12 V Stage Socket
6. Switches: GPS/Video, Avionic,
Turn, Horizont, RDST1,
RDST2, XPDR, Fuel
Pump,ACL, NAV, Camera,
Smoke, Land
7. Propeller adjustment lever
8. Magnetical Compas
9. GSP
10. COM1, COM2
11. Audio panel
12. Transponder
13. Starter Key, Magnetos
14. Master Switch
15. Altimeter
16. Throttle Lever
17. Rescue system lever
18. Vario
19. Cabin heating
20. Cabin ventilation
21. Fuel Selector
22. Choke Lever
23. Trim switch Pilot/copilo
24. Trim indicator
25. Buttons: Trim, PTT
26. Wheel Brake Lever
27. Flap Control
28. Horizont
29. Turn coordinator
30. Manifold pressure
31. Tachometer
32. Fuel tanks left, right
33. Oil pressure
34. Fuel pressure
35. Oil temperature
36. CHT
37. Engine hours indicator
38. Pedal adjustment
39. Switch Analog/D180
40. Circuit-breakers*
* to see next page
Date: 1.12.2001
3
18
16
2
12
10
31
5
6
1
14
13
15
11
20
17
22
21
23
24
26
27
9
8
33
7
4
28
25
29
32
19
30
25
34
35
36
37
38
38
39
