AES global CellCOM PRIME - Technical Specifications

P a g e | 21
Technical Specifications
GENERAL
Front Panel
Portrait Orientation
AB/ABK = 3mm Acrylic on Architectural Design Marine Grade
Stainless Steel BS316 Front Plate
AS/ASK = 3mm Marine Grade Stainless Steel BS316 on
Architectural Design Marine Grade Stainless Steel BS316 Front
Plate
FS/FSK = Flush Design Marine Grade Stainless Steel BS316 Front
Plate
IMP/IMPK = 3mm Acrylic on Imperial Design Marine Grade
Stainless Steel BS316 Front Plate
Landscape Orientation
PED = Pedestal Surface Mount. Powder Coated Marine Grade
Stainless Steel BS316 Front Plates with 3mm Acrylic on Design
Marine Grade Stainless Steel BS316 Modular Plates
Hood Cover (MOD, IMP(K),
PED)
Powder coated Aluminium
Mounting Housing (Backbox)
Marine Grade Stainless Steel BS316
Mounting Type
AB/AS/ABK/ASK = Surface-Mounted with backlighting,
IMP/IMPK = Surface-Mounted,
FS/FSK = Flush-mounted
Call Button
Stainless-steel button with illuminated LED Ring (max. 4
separate buttons)
Power Supply
24V DC
Power Consumption
GSM PCB w/Keypad & Prox
Standby Current: 80mA
Dial Out: 300mA
Max Current: 2A
Solar Power
30Watt Solar Panel (minimum)
2x 12V 10AH Batteries connected in series to provide 24V
output. The power output must be regulated.
Ingress Protection:
IP55
Approvals
FCC, CE
Dimensions
See catalogue
Operating Temperatures
-25 to +55°C / -13 to 131°F
KEYPAD MODULE
Backlighting
Blue / White
