DILUMAT S® MA108201-C
52
7. USE
7.1 Installing the tube into the pump
To ensure that the pump operates properly and that diluent is dispensed accurately, it is
essential that the pre-sterilized distribution tube be placed into the device
correctly.
Follow steps 1 through 3 in the diagrammed procedure below:
4. Lift the cover of the pump head.
5. Turn the knob to adjust for the interior diameter of the tube used (dilution: 6.4mm).
