AFG 3.5AE - Page 36

36
CHAPTER 5: Part Replacement Guide
5.2.6 Side cover Replacement
1. Loose the 4 screws on the side cover (Figure A)
2. Loosen the screws in the cover as shown below（Figure B）
Figure A Figure B
3. After removing the side cover, you will see the inside structure (Figure C).
Figure C
