AFG 3.5AE - Page 37

37
CHAPTER 5: Part Replacement Guide
5.2.7 ECB Motor Replacement
1. Loosen the 2 different screws as shown below (Figure A).
Figure A
2. Loosen the screws on the opposite side (Figure B), and then remove the belt. Take off the ECB.
Figure B
