Afikim Caddy - Placing the Batteries

Caddy
22
2.4 Placing the batteries
The batteries are mounted in a special plastic housing by sliding it
inside. The batteries electric connections is done at the same stage
when sliding it into the housing guide .
Please refer to figure 5: Place both batteries in their place at the rear of
the frame by sliding them into the housing guides in the arrow direction .
Make sure that when the batteries are completely down , the two snaps
1 are seating in the slots 2 of the battery housing.
Figure 5
