Afikim Caddy - Drive Characteristics; Drive System and Tires

Caddy
7
1.2.4 Drive characteristics
Speeds
Maximum speed forward (hare symbol) 7,5 km/h.
Slow speed forward (tortoise symbol) 4,5 km/h.
Reverse speed 4,5 km/h.
Turning radius 75.0 cm.
Ground clearance 8 cm.
Maximum obstacle height 3 cm.
Maximum safe slope 3°
Range according ISO 7176-4 20 km.
(Range is dependant on the circumstances during use, it can be
less i.e when hills, wind or loose surface such as gravel or sand.
Range can also vary with the user weight)
1.2.5 Drive system and tires
Drive system front wheel, worm wheel reduction direct drive
Motor 24 Volt / 200 Watt.
Motor controller (complies with ISO7176-14) 24 Volt / 60 Amp.
programmable
Brake systems - Regenerative motor brake
- electro-magnetic parking brake
Tires
PU tire size Ø 250x50
Tire size (inflatable) Ø 250x50 (10”x2”)
ETRTO: 54-152
Tube size (with right angle valve) 10”x2”
ETRTO: 54-152
Tire pressure (when using inflatable tires) 2,4 bar.
