Caddy
43
4.3 Removing the basket
Remove the basket from the rear part of the Caddy . See figure 7.
4.4 Removing the batteries
• To remove the batteries from their housing , pull up
each one of the batteries with it’s handle upward . This
action will release the batteries securing snaps (1) from
the housing slots (2).
No need to connect any electric connection this is done at the
same one action . For illustration see figure 16
ATTENTION:
Danger of pinching your hand: please follow the instructions and make
sure your hand does not get caught between the battery and other parts
of the frame. The weight of the batteries represent an additional hazard
when you are handling them.
