8. ON/OFF light
Green light is lit when you turn the key switch to the ON position.
9. Reverse driving
This arrow indicates the left throttle handle is intended for reverse
driving.
10. Forward driving
This arrow indicates the right throttle handle is intended for forward
driving.
11. Light symbol
The light symbol indicates the location of the red light switch at the lower
front of the panel below the symbol.
12. Trumpet symbol
The trumpet symbol indicates the location of the yellow horn switch
located at the lower front of the panel below the symbol.
13. Tortoise symbol
This symbol indicates the low-speed setting of the high-speed/ low-
speed switch located below the symbols.
14 Hare symbol
This symbol indicates the high-speed setting of the high-speed / low-
speed switch located below the symbols.
15. Battery discharge indication lights
The four red lights with the triangular symbol underneath show the
charge status of you batteries.
