4 Pin Console pinout
SFA-32 Power In/ Alarm Out
Pin #
Description
1
12 VDC IN (red)
2
-12VDC IN (black)
3
Visual Alarm Out (rd/wh)
4
Visual Alarm Return (bk/wh)
30 Pin Console Pinout
SFA-32 Console Connector
Pin #
Description
A1
Row 1 (green)
A2
Row 2 (white)
A3
Row 3 (brown)
B1
Row 4 (blue)
B2
Row 5 (orange)
B3
Row 6 (yellow)
C1
Row 7 (violet)
C2
Row 8 (grey)
C3
Row 9 (pink)
D1
Row 10 (tan)
D2
Row 11 (white/black)
D3
Row 12 (red/black)
E1
Row 13 (green/black)
E2
Row 14 (orange/black)
E3
Row 15 (blue/black)
F1
Row 16 (black/white)
F2
Row 17 (red/white)
F3
Row 18 (green/white)
G1
Row 19 (blue/white)
G2
Row 20 (black/red)
G3
Row 21 (white/red)
H1
Row 22 (orange/red)
H2
Row 23 (blue/red)
H3
Row 24 (red/green)
J1
Vac 2 (purple)
J2
Vac 3 (gray)
J3
No Connection
K1
Lift Switch Signal (green/bk/red)
K2
8 V Sensor Power (red)
K3
8 V sensor Ground (black)
