OPERATOR’S MANUAL
24
SFA-32
10 Pin Accessory Harness Pinout
SFA-32 Accessory Harness
Pin #
Description
A
Hopper Level 1 (green)
B
Hopper Level 2 (white)
C
RPM 1 (brown)
D
RPM 2 (blue)
E
RPM 3 (orange)
F
Vac 1 (yellow)
G
Vac 2 (purple)
H
Vac 3 (gray)
J
8 V Sensor Power (red)
K
8 V Sensor Power (black)
4 Pin Rear Console pinout (Radar/Speed)
SFA-32 External Speed In
Pin #
Description
1
Ground (black)
2
Signal (green)
3
12 v. Power (red)
4
Sense (white)
