29
HOTCUPBOARD POWER
SUPPLY
Mains cable fed from control tray right-
hand exit through ducting dependent
upon position of supply socket
DESN 517786
DESN 517785
Fig. 16.3
Fig. 16.4
Mains cable routing- AGA Hotcupboard
THE MAINS SUPPLY CONNECT POINT MUST BE WITHIN THE ZONES SHOWN
6ft 6” radius hotcupboard cable
3ft 11” radius
AGA cable
4ft 11” radius AGA cable
