AGA R7 - Page 5

1. Product Safety 1
2. Health & Safety 3
3. Introduction 5
4. Overview 6
AGA R7 100 6
AGA R7 150 7
5. How to use your AGA R7 8
Getting to know your AGA 8
Oven Controls 9
Hotplate Controls 10
Operating the ovens 10
Operating the Hotcupboard 11
General Advice 12
6. Equipment supplied
with your AGA eR7 13
7. Fitting and Removing
the oven shelves 15
8. Fitting and removing
the oven doors 16
9. Cooking on your AGA 17
10. Cleaning & Caring 18
11. Installation instructions 19
12. Installation requirements 20
13. Location 21
14. Clearances 22
AGA R7 100 24
AGA R7 150 25
15. Power Supply connections 26
AGA Hotcupboard connections 27
16. Mains Supply Location 28
Mains cable routing 28
Mains cable routing- AGA Hotcupboard 29
17. Hotcupboard installation 30
18. Circuit diagram 37
R7 Circuit diagram 37
AGA R7 (HOTCUPBOARD) 38
Contents
