Rear panel
At the rear side of the printer, one slot and three connectors are available:
1
CF-card slot
• To insert an external CF-card for software
installation, backup, etc.
2
Network
connector
• To connect a remote PC (used for access via the
web browser pages).
3
Input/output
connector
• To connect a terminal PC (used by the Service
engineer).
4
Power
connector
• To connect the printer power cord.
"
!
