AGFA DX-D 40C - Page 13

1
2
4
3
1.
DR Detector
2.
DR Detector connector cable (wired configuration)
3.
System Control Unit
4.
Workstation
Figure 2: DR Detector configuration (wired)
6
5
1
4
2
3
DX-D 40C, DX-D 40G | Introduction to the DR Detector | 13
0290B EN 20190401 1627
