Attaching the Handle Unit with Grid
1
2
To attach the handle unit for making exposures using the grid
1. Lay down the grid on a flat surface.
2. Lay the DR Detector in the grid, bottom edge first, with the tube side
facing down (1).
3. Attach the grid to the DR Detector (2).
WARNING:
Use only the grid that is supplied as option to the DR
Detector.
