Attaching the handle unit with grid
1
2
CAUTION:
To safely attach the handle unit for making exposures using the
grid, follow these instructions.
1. Lay down the grid on a flat surface.
2. Lay the DR detector in the grid, bottom edge first, with the tube side
facing down (1).
3. Attach the grid to the DR detector (2).
WARNING:
Use only the grid that is supplied as option to the DR
detector.
