Source Voltage Accuracy Test
Source Voltage Accuracy Test
The 4339B’s source voltage is measured with a DC voltmeter.
Specification
Test Equipment
Procedure
WARNING When the High Voltage indicator is lit, the 4339B outputs high voltages of up to 1000
Vdc maximum.
Step 1. Reset the 4339B using the following procedure:
1. Press [blue][⋅] to display the system reset menu.
2. Select Yes using [←][↓ ]or [↑][→] and press [Enter].
Step 2. Set up the equipment as shown in Figure 1.
Source Voltage (Vs) Accuracy: ± (0.16 % + 100mV) (Vs≤200V)
± (0.16 % + 500mV) (Vs>200V)
Description Recommended Model
Multimeter 3458A
V Measurement Adapter PN 04339-65006
Banana-Banana Jumper 11508A
