Agilent Technologies 490 Micro GC User Manual

Checkout Information 2
Natural Gas Analyzers 18
Natural Gas Analyzer B and B Extended Version
PoraPLOT U
The PoraPLOT U channel of the Agilent 490 Micro GC - Natural
Gas Analyzer B and Extended version is specified for the
analysis of methane, carbon dioxide, ethane, hydrogen sulfide,
and propane in natural gas samples. The total sample path of
this channel is deactivated (Ultimetal), which results in better
performance and peak shape for hydrogen sulfide.
Analysis of the NGA Gas Calibration standard results in a
chromatogram similar to Figure 16.
Figure 16 NGA Gas Calibration standard analyzed with the PoraPLOT U channel on Analyzer B
Seconds
20 25 30 35 40 45 50 55 60 65
mV
0
100
200
300
400
Nitrogen
Carbon Dioxide
Ethane
Propane
Methane
