106 5975/5977 Series MSD Operation Manual

4 General Maintenance

3 Collect the following parts to be cleaned for an extractor EI ion source:

(See Figure 15 on page 107.)

• Repeller

• Insulator

• Source body

• Extractor lens

• Ion focus lens

• Entrance lens

These are the parts that contact the sample or ion beam. The other parts

normally should not require cleaning.

CAUTION

If insulators are dirty, clean them with a cotton swab dampened with reagent-grade

methanol. If that does not clean the insulators, replace them. Do not abrasively or

ultrasonically clean the insulators.
