Operating in Electron Ionization (EI) Mode 3
5975/5977 Series MSD Operation Manual 59
Turbo Pump Speed Displays the turbo pump speed.
Foreline Pressure Displays the foreline pressure.
MSD Fault Status Reports a summary fault status code (number) in ‘dec’ (decimal) and
‘hex’ (hexadecimal) format covering all possible fault combinations.
Ion Source Temp,
o
C Displays and sets the ion source temperature.
Mass Filter Temp,
o
C Displays and sets the mass filter temperature.
CI Reagent Displays CI reagent gas and flow rate (if installed).
Table 10 MS Parameters menu (continued)
Action Description
NOTE
MS parameters cannot be set from the LCP while an online OpenLAB CDS session is
connected to the MSD.
Table 11 Network menu
Action Description
MSD IP via BootP Displays the IP address for the MSD.
Gateway IP Address Displays the gateway IP address for the MSD.
Subnet Mask Displays the subnet mask for the MSD.
ChemStation IP Displays the IP address for the OpenLAB CDS PC.
GC IP Address Displays the IP address for the GC.
Ping gateway Checks communication with the gateway.
Ping ChemStation Displays the IP address for the OpenLAB CDS PC.
Ping GC Checks communication with the GC.
MS Controller MAC Displays the MAC address of the SmartCard in the MSD.
Table 12 Version menu
Action Description
Control firmware Displays the MSD firmware version.
