Agilent Technologies 654 A Series Service Manual

Verification 21
Table 2-6. Performance Test Record for Agilent Model 6542A or 6642A
MODEL Agilent _____________
Report No.______________ Date_____________________
Test Description
Minimum
Spec.
Results
*
Maximum
Spec.
Constant Voltage Tests
Voltage Programming
and Readback
Low Voltage (0 V) V
out
Front Panel Display Readback
-10 mV
V
out
- 15 mV
________mV
________mV
+10 mV
V
out
+ 15 mV
High Voltage (20 V) V
out
Front Panel Display Readback
19.978 V
V
out
- 29 mV
_________V
_______mV
20.022 V
V
out
+ 29 mV
Load Effect
V
out
- 2 mV _______mV V
out
+ 2 mV
Source Effect
V
out
- 0.5 mV _______mV V
out
+ 0.5 mV
PARD (Ripple and Noise)
Peak-to-Peak
RMS
0
0
_______mV
_______µV
3 mV
300 µV
Transient Response Time
(at 100 µs)
0 _______mV 20 mV
Constant Current Tests
Current Programming
and Readback
Low Current (0 A) I
out
Front Panel Display Readback
-13 mA
I
out
- 9.1 mA
_______mA
_______mA
+13 mA
I
out
+ 9.1 mA
High Current (10 A) I
out
Front Panel Display Readback
+ 9.972 A
I
out
- 24.1 mA
_________A
_______mA
+10.028 A
I
out
+ 24.1 mA
Current Sink (2 A) Display Readback
I
sink
- 27 mA _______mA I
sink
+ 27 mA
PARD (Ripple and Noise)
RMS
0 ________mA 5 mA
Load Effect
I
out
- 0.5 mA ________mA I
out
+ 0.5 mA
Source Effect
I
out
- 0.5 mA ________mA I
out
+ 0.5 mA
*Enter your test results in this column.
