2 - Verification and Performance Tests
20
Performance Test Record Forms
Model Agilent 66332A OR Agilent6632B
Report No _______________ Date __________________
Test Description Minimum
Specs.
Results* Maximum
Specs.
Constant Voltage Tests
Voltage Programming and Readback
Low Voltage (0V) Vout
Front Panel Display Readback
High Voltage (Full Scale) Vout
Front Panel Display Readback
− 10 mV
Vout − 3 mV
19.980 V
Vout − 9 mV
__________
__________
__________
__________
+ 10 mV
Vout + 3 mV
20.020 V
Vout + 9 mV
Load Effect − 2 mV __________ + 2 mV
Source Effect − 0.5 mV __________ + 0.5 mV
PARD (Ripple and Noise)
Peak-to-Peak
RMS
N/A
N/A
__________
__________
+ 3 mV
+ 0.3 mV
Transient Response
Voltage in 100 µs Vout − 20 mV __________ Vout + 20 mV
Constant Current Tests
Current Programming and Readback(High Range)
CC Programming Accuracy @ 0A
Current Readback Accuracy @ 20mA (High Range)
CC Programming @ Full Scale
Current Readback Accuracy @ Full Scale
− 3.32mA
Iout − 0.54 mA
4.9955 A
Iout − 10.5 mA
__________
__________
__________
__________
+ 3.32 mA
Iout + 0.54 mA
5.0045 A
Iout + 10.5 mA
Current Sink Readback Isink − 11.1mA __________ Isink + 11.1mA
20 mA Range Current Readback
Readback Accuracy @ 0 A
Readback Accuracy @ + 20 mA
Readback Accuracy @ − 20 mA
− 2.5 µA
Iout − 22.5 µA
Iout − 22.5 µA
__________
__________
__________
+ 2.5 µA
Iout + 22.5 µA
Iout + 22.5 µA
PARD (Current Ripple and Noise)
RMS N/A __________ + 2.0 mA
Load Effect − 1.0 mA __________ + 1.0 mA
Source Effect − 0.5 mA __________ + 0.5 mA
* Enter your test results in this column
