Replaceable Parts List
Introduction
This section lists the replaceable parts for Agilent Models 66332A, 6632B, 6633B, and 6634B
power supplies. Refer to Figures 5-1 for the location of mechanical parts with the reference
designators MP. Refer to the board location diagrams in Chapter 6 for the location of electrical
parts.
Table 5-1. Chassis, Electrical
Designator Model Part_Number Qty Description
A1 66332A/6632B 5063-3431 1 Control PCA, Tested
A1 6633B 06633-61023 1 Control PCA, Tested
A1 6634B 06634-61023 1 Control PCA, Tested
A2 66332A 5063-3439 1 Interface PCA, Tested
A2 6632B/6633B/6634B 5063-3429 1 Interface PCA, Tested
A3 All 5063-3432 1 Front Panel PCA, Tested
A4 6633B/6634B 5063-3406 1 Binding Post PCA
A4 66332A/6632B 06611-60022 1 Binding Post PCA
A5 All 5063-3433 1 AC Input/RFI PCA
A6 All 5063-3434 1 Relay PCA, Tested
B1 All 06632-60002 1 Fan Assembly
T1 66332A/6632B 9100-5501 1 Main Transformer
T1 6633B 9100-5567 1 Main Transformer
T1 6634B 9100-5568 1 Main Transformer
S1 All 3101-2862 1 Rocker Switch (AC Line)
W1 All 06612-80001 1 Cable (A5 to S1)
W2 All 06612-80002 1 Cable (S1 to T1)
W3 All 06632-80004 1 Cable (T1 to A1J303)
W4 All 06612-80008 1 Cable (T1 to A1 J304/J305)
W5 All 06612-80003 1 T1 Jumper
W6 All 5080-2452 1 Cable (A1 to A2 J206)
W7 All 5080-2448 1 Cable (A1 to A2 J207)
W10 All 5080-2457 1 Cable (A2 J210 to A6 J610)
W11 All 5080-2457 1 Cable (A2 J211 to A3 J111)
W15 All 06612-80010 1 Cable (A1 J314 to A4 J615)
All 8120-4383 1 Line Cord, Standard (Option 903)
All 8120-1350 1 Line Cord, Option 900
All 8120-1369 1 Line Cord, Option 901
All 8120-1689 1 Line Cord, Option 902
All 8120-0698 1 Line Cord, Option 904
All 8120-2104 1 Line Cord, Option 906
All 8120-2956 1 Line Cord, Option 912
All 8120-4211 1 Line Cord, Option 917
All 8120-4753 1 Line Cord, Option 918
