Replaceable Parts 89
Table 5-3. Main Chassis, Replaceable Parts (continued)
Ref. Desig. Agilent Part No. Description
MECHANICAL PARTS (continued)
-- -- Bus bar, plus (Model specific)
6571A 6671A 06671-00009
6572A 6672A 06671-00009
6573A, 6673A 5001-6751
6574A, 6674A 5001-6751
6575A, 6675A 5001-6751
-- 5041-8819 Cap strap handle
-- 5041-8820 Cap strap handle
-- 5060-3334 Chassis assy
-- 1400-0611 Clamp cable (phone cable)
-- 1531-0309 Clevis (A2 GPIB bd)
-- 9170-1138 Core mtg assy
-- 5001-6745 Cover
-- 5001-6758 Fan bracket
-- 5001-6747 FET chassis
-- 5020-2741 FET heat sink
-- 5001-6748 Front panel
-- 5040-1664 Front panel frame
-- 5020-2740 Heatsink diode
-- 0340-0458 Insulator mica (FETs to heat sink)
-- 0370-3238 Knob (front panel RPG control)
6571A 06571-80001 Nameplate
6572A 06572-80001 Nameplate
6573A 06573-80001 Nameplate
6574A 06574-80001 Nameplate
6575A 06575-80001 Nameplate
6671A 06671-80001 Nameplate
6672A 06672-80001 Nameplate
6673A 06673-80001 Nameplate
6674A 06674-80001 Nameplate
6675A 06675-80001 Nameplate
0590-0534 Nut self-threading (display to front panel)
-- 0535-0002 Nut hex (shunt to PCB)
-- 0535-0031 Nut hex w/lockwasher (bus bar to A6 output bd)
-- 0590-0305 Nut hex w/lockwasher (L901,902 brkt)
-- 0535-0031 Nut hex w/lockwasher M3X.5 2.4 mm( fan to bracket)
-- 0590-0305 Nut hex w/lockwasher 6-32 thrd .094 in thk
(ground wire to rear panel)
-- 2550-0084 Nut hex (bus bar)
-- 2950-0144 Nut hex (rear panel gnd post)
-- 0905-0193 O-ring 1.12in (input caps)
-- 5001-6746 output chassis (sense term)
-- 5080-2184 Rear label
-- 5001-6743 Rear panel
-- 5040-1674 Safety cover dc output
-- 5040-1676 Safety cover ac input
