Code Message Cause
+ 2003 Invalid word address An odd address was specified for a 16 bit read or write.
Alw ays use even addresses for 16 bit (word) accesses.
+ 2005 No module at logical address A non-existent logical address was specified with the
VXI:READ? or VXI:WRITE command.
+ 2101 Failed Device VXI device failed its self test.
+ 2102 Unable to combine device Device type can not be combined into an instrument such as
a scanning multimeter or a sw itchbox.
+ 2103 Config warning, Device driver
not found
ID of device does not match list of drivers available. Warning
only.
+ 2105 Config error 5, A24 memory
overflow
More A24 memory installed in the mainframe than can be
configured into the available A24 memory space.
+ 2108 Config error 8, Inaccessible
A24 memory
A24 memory device overlaps memory space reserved by the
mainframe’s operating system.
+ 2110 Config error 10, Insufficient
system memory
Too many instruments installed for the amount of RAM
installed in the mainframe. Cannot configure instruments.
Only the system is started.
+ 2111 Config error 11, Invalid
instrument address
A device’s logical address is not a multiple of 8 and the
device is not part of a combined instrument.
+ 2113 Config error 13, Logical
address or IACK switch set
wrong
Duplicate logical addresses set or interrupt bypass switches
set improperly. Only the system is started.
+ 2129 Config warning, Sysfail
detected
A device was asserting SYSFAIL on the backplane during
startup.
+ 2130 Config error 30, Pseudo
instrument logical address
unavailable
A physical device has the same logical address as IBASIC
(240).
+ 2131 Config error 31, File system
start up failed
Insufficient system resources to allow IBASIC file system to
start.
+ 2145 Config warning, Non-volatile
RAM contents lost
NVRAM was corrupted or a cold boot was executed.
+ 2148 Config warning, Driver RAM
contents lost
Driver RAM was corrupted or a cold boot w as executed.
+ 2202 Unexpected interrupt from
non-message based module
A register-based module interrupted when an interrupt
service routine had not been set up.
+ 2809 Interrupt line has not been set
up
A DIAG:INT:ACT or DIAG:INT:RESP command was executed
before setting the interrupt with DIAG:INT:SET.
Table A-4. System Errors (cont.)
A-6 In Case Of Difficulty
