Agilent Technologies 8960 Series Programming Guide

71
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\Chapters\prog_prog_guide_comprehensive_prog_example.fm
Comprehensive Program Example
590 PRINT USING “5X,””Maximum:””,M2D.2D,”” dBm”””;Txpower(2)
600 PRINT USING “5X,””Average:””,M2D.2D,”” dBm”””;Txpower(3)
610 PRINT USING “5X,””Std Dev:””,M2D.2D,”” dB”””;Txpower(4)
620 ELSE
630 GOSUB Bad_measurement
640 END IF
650 CASE “PFER”
660 OUTPUT Test_set;”FETC:PFER:ALL?”
670 ENTER Test_set;Integrity,Rms_phas_err,Peak_phas_err,Worst_freq_err
680 IF (Integrity=0) THEN
690 PRINT “PFERror results: TCH =”;Traf_chan;”and TXL =”;Ms_pwr_lvl
700 PRINT USING “5X,””RMS Phase Error:””,M2D.2D,”” deg”””;Rms_phas_err
710 PRINT USING “5X,””Peak Phase Error:””,M2D.2D,”” deg”””;Peak_phas_err
720 PRINT USING “5X,””Worst Freq Error:””,M3D.2D,”” Hz”””;Worst_freq_err
730 ELSE
740 GOSUB Bad_measurement
750 END IF
760 CASE “ORFS”
770 OUTPUT Test_set;”FETC:ORFS:INT?”
780 ENTER Test_set;Integrity
790 IF (Integrity=0) THEN
800 OUTPUT Test_set;”SET:ORFS:SWIT:FREQ:POIN?”
810 ENTER Test_set;Points
820 IF Points THEN
830 ALLOCATE Orfs_swit_res(Points),Orfs_swit_offs(Points)
840 OUTPUT Test_set;”SET:ORFS:SWIT:FREQ?;:FETC:ORFS:POW?;:FETC:ORFS:SWIT?”
850 ENTER Test_set;Orfs_swit_offs(*),Tx_power,Orfs_swit_res(*)
860 PRINT “ORFS Swit Results: TCH =”;Traf_chan;”and TXL =”;Ms_pwr_lvl
870 PRINT USING “19X,””TX Power =””,M2D.2D,”” dBm”””;Tx_power
880 PRINT “ Offset(kHz) Level(dBm)”
890 PRINT “ ----------- ----------”
900 Orfs_image: IMAGE 6X,M4D.2D,12X,M4D.2D
910 FOR J=1 TO Points
920 PRINT USING Orfs_image;(Orfs_swit_offs(J)/1.E+3),Orfs_swit_res(J)
930 NEXT J
940 DEALLOCATE Orfs_swit_res(*),Orfs_swit_offs(*)
950 END IF
960 OUTPUT Test_set;”SET:ORFS:MOD:FREQ:POIN?”
970 ENTER Test_set;Points
980 IF Points THEN
990 ALLOCATE Orfs_mod_res(Points),Orfs_mod_offs(Points)
1000 OUTPUT Test_set;”SET:ORFS:MOD:FREQ?;:FETC:ORFS:POW?;:FETC:ORFS:MOD?”
1010 ENTER Test_set;Orfs_mod_offs(*),Tx_power,Pwr_30khz,Orfs_mod_res(*)
1020 PRINT “ORFS Mod Results: TCH =”;Traf_chan;”and TXL =”;Ms_pwr_lvl
1030 PRINT USING “18X,””30 KHz BW Power =””,M2D.2D,”” dBm”””;Pwr_30khz
1040 PRINT “ Offset(kHz) Level(dB)”
1050 PRINT “ ----------- ---------”
1060 FOR J=1 TO Points
1070 PRINT USING Orfs_image;(Orfs_mod_offs(J)/1.E+3),Orfs_mod_res(J)
1080 NEXT J
1090 DEALLOCATE Orfs_mod_res(*),Orfs_mod_offs(*)
1100 END IF
1110 ELSE
