Agilent Technologies B1500A Training Manual

Required Devices for Class Exercises
To perform the class exercises, you need the device set (Agilent part number 04156-87001)
which contains the following devices.
Description Quantity
N-channel MOSFET 2 ea.
NPN Bipolar Transistor 1 ea.
Red Miniature LED 1 ea.
0.1 μF Cap
acitor 50 V 1 ea.
1.0 Ω Re
sistor 1/8 W 1 ea.
1.1 kΩ Resi
stor 1/8 W 1 ea.
511 kΩ Resistor 1/8 W 1 ea.
NPN bipolar TransistorN-ch MOSFET LED
1 ohm Resistor
Brown
Black
Black
Silver
1.1 kohm Resistor
Brown
Brown
Black
Brown
511 kohm Resistor
Green
Brown
Brown
Orange
0.1 uF Capacitor
