Required Accessories for Class Exercises
To perform the class exercises, you need the following accessories. Prepare the accessories
shown below.
Designation Description Model No. Qty.
1 Test Fixture
16442A/B
a
a. The 16058A Test Fixture for the 4145A/B may be substituted for the
16442A/B Test Fixture. If you use the 16058A, you also need the 16435A
Interlock Adapter.
1 ea.
28 pin socket module 1 ea.
Connection wire 6 ea.
2 Triaxial Cable 16494A 4 ea.
3 Interlock Cable 16493J 1 ea.
4 Kelvin Triaxial Cable, for Module 5 16493K 1 ea.
5 CMU Cable, for Module 8 N1300A 1 ea.
6 Atto Sense/Switch Unit, for Module 6 E5288A 1 ea.
ASU control cable, triax cable, for Module 6 16493M 1 ea.
16442A/B Test Fixture (1ea.)
Triaxial Cable (4ea.)
INTLK Cable (1ea.)
Connection Wire (6ea.)
28 pin DIP Socket Module (1ea.)
2
3
1
4
5
CMU Cable (1ea.)
6
E5288A ASU (1ea.)
Triaxial Cable (1ea.)
Control Cable (1ea.)
Kelvin Triaxial Cable (1ea.)
To Next Page
